BUTYL (IIR) COATED ARAMID FABRIC

Fiber consisting of a long chain polymer containing amines and aromatic components. Infusible, does not melt, does not burn, does not soften. Besides it shows low emission of toxic gases while combustion. Certain aramid can decompose at 500° C, It is thermostable up to 250° C.

Butyl, also known as Isobutylene-isoprene (IIR), is a synthetic rubber developed in the 1940’s. It has exceptionally low gas permeability making it ideal for inner tubes and high pressure/vacuum sealing applications. Its very low resilience makes it suitable for shock and vibration damping. Its chemical unsaturation gives it excellent resistance to heat, ozone, and weathering, and also to dilute acids and alkalis.
It is not suitable for use in mineral or petroleum based fluids.

General Properties	min - max
Warp breaking strength	350 - 5000 daN/5cm
Weft breaking strength	350 - 2000 daN/5cm
Warp elongation at break	2% - 5%
Weft elongation at break	2% - 5%
Weight per sqm	from 450 gr/m2
Thickness	Upon request
Peeling strength	Upon request
Continuous Temperature	-55 C° à 120C°
Point Temperature	-55 C° à 130C°

Properties

Acids resistance

Non-skid

UV resistance

Ozone Resistance

General Properties	min - max
Warp breaking strenght	350 - 5000 daN/5cm
Weft breaking strenght	350 - 2000 daN/5cm
Warp elongation at break	2% - 5%
Weft elongation at break	2% - 5%
Weight per sqm	100 - 650

General Properties	min - max
Hardness ShA	30 - 90 ShA
Hardness IRHD	30 - 90 IRHD
Tensile Strength	8 MPa - 20 MPa
Elongation at break	100% - 900%
Operating temperature
Continuous Temperature	-55 C° - 120C°
Point Temperature	-55 C° - 130C°

Resistance
Solvent resistance
Acid resistance
oxygen ageing
Ozone ageing
light ageing
Cold ageing	--
heat ageing	--

Available colors :

High temperature filtration.
Clothing fire protection.
Bullet proof vest. Thermo industry, electric and electronic.
Aerospace industry, boats and inflatables, sun protection.
